22WDP-114 - Belimo Differential Pressure Sensor Water L=0...4 bar, DC 0...10 V
£399.00
£332.50
On request
Next Supplier Stock Update: 18/10/2026
Manuals & Datasheets
|
MANUAL |
MOUNTING INSTRUCTIONS |
BROCHURE |
 |
|
|
| IP rating | IP65 |
| Output Signal | 0..10Vdc |
| Manufacturer | Belimo |
| Power Supply | 24Vac/Vdc |
| Sensor Type | Water Differential Pressure Transducer |
| Pressure range | 0 to 4 Bar |
Explore all the components for your ventilation system at iacs. All Belimo Differential Pressure Sensors in stock are ready for delivery with either Free or 1-2 Days Delivery.
The Belimo 22WDP-114 is a Sensor used in HVAC applications and it is a device that provides an precise measurement of Differential Pressure.
To keep track of the pressure differences between air and other non-flammable, non-aggressive gases. Keeping an eye on fans, air filters, industrial cooling cycles, and air and fire dampers.
IACS has the most economical Belimo Sensors for your system.
If you have any inquiries about installation or size, please see the aforementioned Belimo custom datasheet or contact iacs via email for personalised assistance.
| Electrical data | Power Supply DC | 15...24 V, ±10%, 0.37 W |
| Power Supply AC | 24 V, ±10%, 0.9 VA | |
| Electrical connection | Plug for wire 0.5...1.5 mm² | |
| Cable entry | Angle plug according to DIN 43650, construction A | |
| Functional data | Output signal active pressure | DC 0...10 V |
| Output signal active note | Voltage output: min. 2 kΩ load | |
| Mechanical connection | pressure connector: G1/4" | |
| Mounting | installation position unrestricted | |
| Media | Water | |
| Measuring data | Measured values | Differential pressure |
| Measuring media | Air and non-aggressive gases | |
| Accuracy pressure | <±1% of measuring range (@ -5...75 °C) | |
| Overload range | 6 bar, Single-sided | |
| Maximum system pressure | 21 bar | |
| Materials | Housing seal | EPDM |
| Housing | Bottom Part: Stainless steel 1.4305 | |
| Top Cover: Aluminum pressure die casting | ||
| Medium wetted parts | Stainless steel 1.4301, Ceramic |
| Optional accessories | Description | Type |
| Pipe connector brass, 2 pcs., Pipe 6 mm to G 1/4" (external thread) | A-22WP-A04 | |
| Pipe connector stainless steel, 2 pcs., Pipe 6 mm to G 1/4" (external thread) | A-22WP-A06 | |
| Pipe connector brass, 2 pcs., Pipe 8 mm to G 1/4" (external thread) | A-22WP-A08 | |
| Pipe connector stainless steel, 2 pcs., Pipe 8 mm to G 1/4" (external thread) | A-22WP-A10 |
