F22040075 - IBC Controls 3-phase Helical Gear Motor 3x230 V, 50 Hz, 40 W / 75 rpm

The IBC Controls F22040075 is a compact, in-line 3-phase helical gear motor rated at 40 W and 75 rpm, designed for continuous-duty applications in HVAC actuator and AHU drive systems. Operating on a 3×230 V, 50 Hz supply, it is fully compatible with variable speed drives (VFDs/inverters), making it well-suited for energy-efficient variable-flow installations.

A built-in thermal contact drawn to the terminal provides overtemperature protection without the need for additional external sensing. The motor carries an IP54 protection rating and a two-year product warranty. Its compact built-in dimensions and motor bracket (included, 3.9 kg total) simplify retrofit and new-build installation alike.

Key features:

• Adapted for variable speed control compatible with VFDs and 3-phase fan speed regulators
• Built-in thermal contact drawn to the terminal integral overtemperature protection
• Compact in-line helical gear design, minimal footprint for tight plant spaces
• IP54 rated suitable for indoor mechanical plant environments
• Two-year product warranty

Technical specification:

• Part number: F22040075
• Rated output: 40 W
• Rated speed: 75 rpm
• Connection voltage: 3×230 V, 50 Hz
• Rated current (at 230 V): 0.39 A
• Gear ratio: 1:18
• Rated torque: 4.1 Nm
• Protection rating: IP54
• Max rotor diameter (at 12 rpm): 1400 mm
• Weight (inc. motor bracket): 3.9 kg
• Warranty: 2 years

Typical applications:

• Rotary Heat Recovery
• HVAC Speed Regulation
• System Protections
