F29000803 - IBC Controls Splice pin, 8mm

The IBC Controls Splice Pin, 8mm (F29000803) is the jointing pin used to connect the ends of an 8mm elastic round belt, forming a continuous closed loop for driving rotary heat exchangers (thermal wheels) in air handling units. It is the correct splice pin for use with the IBC Controls 8mm Round Belt (F29000800).

The 8mm round belt is suited to rotary heat exchanger rotor diameters of up to 1,700mm. A minimum pulley size of 63mm is recommended when using the 8mm belt. The splice pin allows quick, tool-free belt jointing during commissioning or belt replacement on site.

Typical Applications

• Drive belt replacement on IBC Controls rotary heat exchanger drive sets
• Commissioning of new MicroMax, MiniMax, and VariMax drive assemblies
• AHU thermal wheel belt maintenance in commercial and industrial buildings

Part Number Reference

• SKU: F29000803
• Belt diameter: 8mm
• Compatible belt: F29000800 IBC Controls Round Belt, 8mm
• Max rotor diameter (at 12 rpm): 1,700 mm
• Minimum recommended pulley size: 63mm
• Manufacturer: IBC Controls (IBC Control AB, Sweden)
