SKU
GPC361.1A
GPC361.1A - Siemens Damper Actuator 4 Nm, 60/15 s, AC 230 V, modulating
£221.99
£184.99
On request
Next Supplier Stock Update: 17/10/2026
Manuals & Datasheets
| DATA-SHEET |
 |
| Product type | Actuator |
| IP rating | IP54 |
| Input Signal | 0..10 Vdc, 2..10 Vdc |
| Manufacturer | Siemens |
| Power Supply | 115 to 230Vac |
| Torque | 4 Nm |
| Running time | 55 to 60 sec |
| Actuator type | Rotary |
| Fail Safe | Spring Return |
| size | 72 x 124 x 63 mm |
All of the Siemens Actuators that are in stock at IACS are delivered within 5 to 7 working days.
The Siemens GPC361.1A is an Actuator used in air ventilation and HVAC applications to open and close dampers.
The Torque force applied by the GPC361.1A is 4 Nm.
The Power Supply requested for this damper Actuator is 115 to 230Vac.
You may find the ideal Siemens Actuator for your system at IACS for a reasonable price.
If you have questions concerning size or installation, refer to the Siemens custom datasheet above or email IACS for individualised support.
|
Torque |
4 Nm |
|
Air Damper Area |
0.6 m² |
|
Angular Rotation |
90° |
|
Power Consumption |
3.7 VA, 2.2 W |
|
Positioning Time |
Open:60 s, Close:15 s |
|
Positioning signal |
DC 0...10 V
|
|
Spring return function |
Yes |
|
Degree of protection
|
IP54 |
|
Ambient temperature, operation |
-32…55 °C |
|
Dimensions (W x H x D) |
72 x 124 x 63 mm |
|
Operating voltage |
AC 230 V |
|
Auxiliary switch
|
0 |
