QBM3020-10 Siemens Air differential pressure sensor. 0-1000pa range. Linear or square root characteristic.

Explore all the components for your ventilation system at iacs. All Siemens Differential Pressure Sensors in stock are ready for delivery in 5 to 7 working days.

The Siemens QBM3020-10 is a Sensor used in HVAC applications and it is a device that provides an precise measurement of Differential Pressure.

This particular Siemens Sensor is intended to gauge the pressure difference between gases.

Find the best-priced Siemens Differential Pressure Sensor that is compatible with your system at iacs.

If you have questions about size or installation, consult the Siemens custom datasheet above or send an email to iacs to get personalised guidance.

• Pressure-linear characteristic with selectable pressure measuring range
• Operating voltage AC 24 V or DC 13.5…33 V
• Output signal DC 0...10 V
• Zero-point adjustment
• Simple and fast mounting thanks to integrated mounting brackets in the
housing
• Maintenance free
• Calibrated and temperature-compensated measuring signal
• Supplied with tubing connection set

The differential pressure sensor acquires differential, over and under pressure of
air and nonaggressive gases.
Fields of application
• Measuring the slightest differential pressures in ventilation and air conditioning
ducts
• Check air flows
• Monitor filters and control fans
