UU01FDA001 - This product has been phased out

The UU01FDA001 - Ultrasonic humidifier for fan coil, capacity 0.5 l/h is the new ultrasound humidifer developed by Carel It was designed to regulate and keep the desired level of humidity for a specific room at a constant level. humiSonic, installed inside the fan coils, is the ideal solution to combine ordinary temperature control (guaranteed by the fan coils) with carefully controlled humidity. The combination and precise regulation of these two fundamental air characteristics ensure that comfort conditions are achieved and maintained in domestic and commercial environments.

humiSonic is the new ultrasound humidifer developed by Carel It was designed to regulate and keep the desired level of humidity for a specific room at a constant level. humiSonic, installed inside the fan coils, is the ideal solution to combine ordinary temperature control (guaranteed by the fan coils) with carefully controlled humidity. The combination and precise regulation of these two fundamental air characteristics ensure that comfort conditions are achieved and maintained in domestic and commercial environments.

Thanks to the high frequency vibrations of the piezoelectric oscillator (1.7 MHZ), humiSonic is capable of producing extremely fine droplets with a diameter of about 1-5 μm.

The forced channelling system installed between the battery and the air outlet nozzle easily and uniformly distributes the atomised water in the fan coil outlet channel. Providing humiSonic with the humidity probe and flow detector (TAM) creates a complete solution capable of autonomous operation.

Power supply	48 Vac
Power input	100 to 670 VA depending on the model
Operating conditions	5T40 °C, <90% rH
Srorage conditions	-20T70 °C, <90% rH
Water supply	Demineralised water
Water supply conductivity	<5 µsiemens/cm
Water supply pressure	0.5 to 6 bar
Water supply temperature	5T40 °C
Water fill	Quick connection for TNF 8/10 plastic tubing
Water drainage	Connection 13 mm
Overfill drain	Connection: 13 mm
Index of protection	IP30
