VVG44.15-1 - Siemens 2-port seat valve, external thread, PN16, DN15, kvs 1

Find all the components for your ventilation system at IACS. All Siemens Valves in stock are ready for delivery in 5 to 7 days.

The Siemens VVG44.15-1 is a Valve used in HVAC Systems and Building control applications.

This Seat Valve provides a Pressure Nominal of PN 16.

The VVG44.15-1 Siemens Valve has a Diameter Nominal of DN 15.

The Amount of flow that this Ball Valve manages is KWS 1.

Find the best-priced Siemens Seat Valve that is compatible with your system at IACS.

If you have questions about size or installation, consult the Siemens custom datasheet above or send an email to iacs to get personalised guidance.

VVG Valves

In small and medium-sized heating, ventilating and air conditioning systems as
a control valve for mixing and diverting functions or as a shutoff valve. For
closed circuits only.
● Housing made of bronze CC499K
● DN 15...40
● kvs 0.25...25 m3
/h
● Flat sealing, externally threaded connections G..B, as per ISO 228-1
● Siemens can deliver fitting sets ALG.. with threaded connection and ALS.. with
welded connection
● Manual adjustment by means of mounted knob
● Can be equipped with motorized SAS.. actuators
